A Schild – AS Calibre 1526 Watch spare parts
| A Schild – AS Calibre 1526 – Part No. 100 plate |
| A Schild – AS Calibre 1526 – Part No. 105 Barrel bridge |
| A Schild – AS Calibre 1526 – Part No.110 Train-wheel bridge |
| A Schild – AS Calibre 1526 – Part No. 121 Balance cock |
| A Schild – AS Calibre 1526 – Part No. 125 Pallet cock |
| A Schild – AS Calibre 1526 – Part No. 182 Barrel and cover |
| A Schild – AS Calibre 1526 – Part No. 195 Barrel arbor |
| A Schild – AS Calibre 1526 – Part No. 201 Center wheel |
| A Schild – AS Calibre 1526 – Part No. 210 Third wheel |
| A Schild – AS Calibre 1526 – Part No. 224 Fourth wheel |
| A Schild – AS Calibre 1526 – Part No. 240 Cannon pinion |
| A Schild – AS Calibre 1526 – Part No. 250 Hour wheel |
| A Schild – AS Calibre 1526 – Part No. 260 Minute wheel |
| A Schild – AS Calibre 1526 – Part No. 301 Regulator for flat hairspring |
| A Schild – AS Calibre 1526 – Part No. 311 Upper cap jewel with end-piece, for balance |
| A Schild – AS Calibre 1526 – Part No. 330 Lower cap jewel with end-piece,for balance |
| A Schild – AS Calibre 1526 – Part No. 401 Winding stem |
| A Schild – AS Calibre 1526 – Part No. 407 Clutch wheel |
| A Schild – AS Calibre 1526 – Part No. 410 Winding pinion |
| A Schild – AS Calibre 1526 – Part No. 415 Ratchet wheel |
| A Schild – AS Calibre 1526 – Part No. 420 Crown wheel |
| A Schild – AS Calibre 1526 – Part No. 422 Crown wheel ring |
| A Schild – AS Calibre 1526 – Part No. 425 Click |
| A Schild – AS Calibre 1526 – Part No. 430 Click spring |
| A Schild – AS Calibre 1526 – Part No. 435 Yoke |
| A Schild – AS Calibre 1526 – Part No. 440 Yoke spring |
| A Schild – AS Calibre 1526 – Part No. 443 Setting lever |
| A Schild – AS Calibre 1526 – Part No. 445 Setting Iever spring |
| A Schild – AS Calibre 1526 – Part No. 450 Setting wheel |
| A Schild – AS Calibre 1526 – Part No. 705 Escape wheel and pinion |
| A Schild – AS Calibre 1526 – Part No. 710 Jewelled pallet fork |
| A Schild – AS Calibre 1526 – Part No. 721 Complete Balance |
| A Schild – AS Calibre 1526 – Part No. 770 Mainspring |
You can confirm the order by making a PayPal payment. My account email address is [email protected]
Watch Parts Enquiry
* If you are unable to fill out any of the required information fields, please type “N/A”.
Stem, Crown, Hands & Spares might be available for this movement.
Email us for rate and availability: [email protected]
A. Schild (AS) Calibre 1526 Watch Spare Parts: Technical Overview and Sourcing Guide
A. Schild (AS) Calibre 1526 is a vintage Swiss manual-wind mechanical movement, notable for its flat profile and reliable performance during the 1960s. It is essentially a larger version of the AS 1525 calibre with a slightly larger base plate size, maintaining a popular design with 17 jewels and Incabloc shock protection.
Key Technical Highlights
Calibre: AS 1526 (based on AS 1525)
Movement Type: Manual winding, mechanical
Diameter: 25.2 mm (11 1/2 lignes)
Height: 2.8 mm (very flat design)
Jewels: 17 synthetic ruby jewels
Beat Rate: 18,000 vibrations per hour (vph)
Power Reserve: Approximately 44 hours
Lift Angle: 52.23°
Shock Protection: Incabloc system
Winding System: Yoke winding
Balance: Screw-less Glucydur balance with three legs
Period of Use: Circa 1960s
Common Spare Parts and Components
Mainspring and Barrel: Critical for stable power delivery; must match exact dimensions to maintain consistent torque.
Balance Wheel and Balance Staff: Delicate and essential for timing accuracy; include shock protection and require precise compatible replacements.
Pallet Fork and Escape Wheel: Wear-prone escapement parts; original or high-quality NOS parts ensure smooth operation.
Gear Train Wheels: Center, third, and seconds wheels may need replacement due to wear; often sourced from donor movements or NOS stock.
Setting Mechanism: Stem, crown, setting levers, and springs must fit perfectly for reliable winding and time-setting.
Jewels: Synthetic ruby bearings reduce friction; replacements must conform to original configuration for performance and durability.
Hands and Dial Components: Period-correct parts maintain original appearance and collector value.
Sourcing and Maintenance Tips
Prioritize original or NOS parts explicitly marked for AS 1526 or AS 1525 for guaranteed compatibility.
Donor movements are valuable for rare or worn components such as balance assemblies and gear wheels.
Handle delicate parts like the balance and escapement with care during maintenance.
Apply modern synthetic watch oils sparingly, following vintage lubrication standards to maximize movement longevity.
Always verify the calibre number stamped on the main plate before ordering to avoid ordering incompatible parts.
Why AS 1526 Spare Parts Matter
Preserving genuine or precise compatible parts ensures the calibre’s renowned accuracy and reliable manual winding performance.
Correct restoration maintains the vintage watch’s authenticity and collector appeal.
The AS 1526’s well-documented construction facilitates effective sourcing and servicing within watchmaker communities.
The A. Schild AS 1526 remains a respected vintage calibre whose longevity depends on careful sourcing and fitting of quality spare parts to uphold its reliable operation and historical value.
