A Schild – AS Calibre 1595 Watch spare parts
A Schild – AS Calibre 1595 Watch spare parts
| A Schild – AS Calibre 1595 – Part No. 100 plate |
| A Schild – AS Calibre 1595 – Part No. 105 Barrel bridge |
| A Schild – AS Calibre 1595 – Part No.110 Train-wheel bridge |
| A Schild – AS Calibre 1595 – Part No. 121 Balance cock |
| A Schild – AS Calibre 1595 – Part No. 125 Pallet cock |
| A Schild – AS Calibre 1595 – Part No. 182 Barrel and cover |
| A Schild – AS Calibre 1595 – Part No. 195 Barrel arbor |
| A Schild – AS Calibre 1595 – Part No. 201 Center wheel |
| A Schild – AS Calibre 1595 – Part No. 210 Third wheel |
| A Schild – AS Calibre 1595 – Part No. 224 Fourth wheel |
| A Schild – AS Calibre 1595 – Part No. 240 Cannon pinion |
| A Schild – AS Calibre 1595 – Part No. 250 Hour wheel |
| A Schild – AS Calibre 1595 – Part No. 260 Minute wheel |
| A Schild – AS Calibre 1595 – Part No. 301 Regulator for flat hairspring |
| A Schild – AS Calibre 1595 – Part No. 311 Upper cap jewel with end-piece, for balance |
| A Schild – AS Calibre 1595 – Part No. 330 Lower cap jewel with end-piece,for balance |
| A Schild – AS Calibre 1595 – Part No. 401 Winding stem |
| A Schild – AS Calibre 1595 – Part No. 407 Clutch wheel |
| A Schild – AS Calibre 1595 – Part No. 410 Winding pinion |
| A Schild – AS Calibre 1595 – Part No. 415 Ratchet wheel |
| A Schild – AS Calibre 1595 – Part No. 420 Crown wheel |
| A Schild – AS Calibre 1595 – Part No. 422 Crown wheel ring |
| A Schild – AS Calibre 1595 – Part No. 425 Click |
| A Schild – AS Calibre 1595 – Part No. 430 Click spring |
| A Schild – AS Calibre 1595 – Part No. 435 Yoke |
| A Schild – AS Calibre 1595 – Part No. 440 Yoke spring |
| A Schild – AS Calibre 1595 – Part No. 443 Setting lever |
| A Schild – AS Calibre 1595 – Part No. 445 Setting Iever spring |
| A Schild – AS Calibre 1595 – Part No. 450 Setting wheel |
| A Schild – AS Calibre 1595 – Part No. 705 Escape wheel and pinion |
| A Schild – AS Calibre 1595 – Part No. 710 Jewelled pallet fork |
| A Schild – AS Calibre 1595 – Part No. 721 Complete Balance |
| A Schild – AS Calibre 1595 – Part No. 770 Mainspring |
| A Schild – AS Calibre 1595 – Part No. 2535 Date indicator guard |
| A Schild – AS Calibre 1595 – Part No. 2543 Inteimediate date wheel |
| A Schild – AS Calibre 1595 – Part No. 2551 Date plate |
| A Schild – AS Calibre 1595 – Part No. 2556 Date indicator driving wheel |
| A Schild – AS Calibre 1595 – Part No. 2557 Date indicator |
| A Schild – AS Calibre 1595 – Part No. 2575 Date Jumper spring |
| A Schild – AS Calibre 1595 – Part No. 2576 Date Jumper |
You can confirm the order by making a PayPal payment. My account email address is [email protected]
Watch Parts Enquiry
* If you are unable to fill out any of the required information fields, please type “N/A”.
Stem, Crown, Hands & Spares might be available for this movement.
Email us for rate and availability: [email protected]
Mobile/WhatsApp: +91- 9841 360 340
A. Schild (AS) Calibre 1595 Watch Spare Parts: Technical Overview and Sourcing Guide
A. Schild (AS) Calibre 1595 is a vintage Swiss manual-wind mechanical movement, highly regarded for its reliable construction, classic design, and useful features. Produced since at least 1957, it features a small seconds subdial at 6 o’clock and a date window at 3 o’clock, making it popular with collectors and watchmakers restoring mid-20th-century wristwatches.
Key Technical Highlights
Calibre: AS 1595
Movement Type: Manual winding, mechanical
Diameter: Approximately 29.0 – 29.4 mm (13 lignes)
Height: 4.10 mm
Jewels: 17 or 21 synthetic ruby jewels
Beat Rate: 18,000 vibrations per hour (vph)
Lift Angle: 52 degrees
Power Reserve: Around 37–40 hours
Functions: Hours, minutes, small seconds at 6:00, date window at 3:00
Shock Protection: Typically Incabloc or similar Swiss anti-shock device
Escapement: Swiss lever
Common Spare Parts and Service Needs
Mainspring and Barrel: Ensures consistent power delivery; exact replacements essential for torque and durability.
Balance Wheel and Balance Staff: Critical, delicate parts requiring exact fitting and compatible shock protection.
Pallet Fork and Escape Wheel: Wear-prone escapement components; original or high-quality new-old-stock (NOS) parts recommended.
Gear Train Wheels (Minute, Third, Fourth): Subject to wear or pivot damage; typically sourced from donor movements or NOS stock.
Setting Mechanism (Stem, Crown, Levers, Springs): Must fit precisely for reliable winding, time, and date setting.
Jewels: Synthetic ruby bearings positioned to minimize friction; replacements must match original placement and count.
Hands and Dial: Period-correct or original parts preserve vintage authenticity and collector appeal.
Sourcing and Maintenance Tips
Prioritize original, NOS, or donor parts explicitly marked for AS 1595 to ensure compatibility and maintain movement integrity.
Handle fragile components, especially balance wheel and escapement, with care during servicing.
Apply modern synthetic watch oils sparingly, following vintage lubrication standards for optimal longevity.
Always verify the calibre number stamped on the main plate before ordering parts to avoid mismatches.
Why AS 1595 Spare Parts Matter
Authentic parts preserve the calibre’s accuracy, reliability, and vintage character vital for proper function and collector value.
Proper servicing with genuine components supports mechanical longevity and aesthetic authenticity of restored timepieces.
The AS 1595’s well-documented specs facilitate easier sourcing and expert repair support.
Maintaining the A. Schild AS 1595 calibre with quality spare parts is essential to keep these classic Swiss manual-wind watches running reliably and preserving their respected heritage.
